36V Battery
Covering a range of 25 miles per full charge
350W Motor
350w front-drive motor provides reliable support
7-Speed
Easy to switch to 7-speed models
350W High-quality Motor
350w Front-drive motor provides reliable support and a 15.5 mph top speed helps you to ride on terrain change with ease.
36V/10.4AH Capacity Battery
36V/10.4AH Battery with 20A hardware protection board and anti-sparking, covering a range of 25 miles per full charge.
Multi-functional LCD Display
With the LCD display button, you could choose the electric assist level as required, and it also can monitor the riding speed, battery capacity, mileage, power, etc.
Electronics
Motor
350w Front-drive motor provides reliable support
Battery
36V/10.4AH Battery with 20A hardware protection board
Display
LCD display monitors the riding speed, battery capacity, mileage, power, etc
Light
Front headlight is equipped with reflectors
Charger
36V/2A DC2.1, FOC American standard charger
Range
A range of 25 miles per full charge
PAS
12 magnet, double hall, cadence
Throttle
300x, quick release
Top Speed
15.5 mph top speed
Components
Frame
Hi-ten steel frame
Fork
24“, 25.6*25.4*30 206mm steer, dropout 100 width
Shifter
Shimano 7-speed
Derailleur
Shimano 7-speed, direct mount
Crankset
1/2*3/32*36T*152mm
Freewheel
1/2*3/32*14-28T 7-speed
Chain
1/2*3/32* 130L
Brake
Alloy mechanical disc brake set
Brakerotor
Front: 160mm, rear: 140mm
Tire
24*1.95/26*2.125 inch, A/V
Rim
Alloy double wall rims
Spoke
Steel 13G
Hub
Steel 36H
Handlebar
Steel,660*22.2*25.4 H:200mm
Stem
Steel integrated, 25.4*180mm depth ex:80mm
Grip
TPR 120mm Length
Saddle
Comfortable black saddle
Seatpost
Steel, 28.6*300mm
Headset
Steel, 25.4*30mm H:37.5
Basket
Steel and plastic mesh
Fender
24"/26", steel
Geometry
Seat Height: 34.6"~39.4"
Handlebar Distance: 27.5"
Reach: 21.6"
Handlebar Height: 43.3"~47.2"
Frame Height: 17.3"
Rear Wheels Width: 28.3"
Wheelbase: 45.3"
Bottom Brocket Height: 68.9"
Payload Capacity: 350lbs
